IWS-2820M Mini Micro Open Barrel Crimping Tool

IWS-2820M Mini Micro Open Barrel Crimping Tool Works on AWG28-20 JAM, Molex, Tyco, JST Terminals

by iCrimp Tools
$25.99
$25.99 - $25.99
$25.99
$16.99
$16.99 - $16.99
$16.99

About this item

  • Purpose: IWS-2820M open barrel crimper is designed to crimp non-insulated open barrel, OEM-style terminals. Perfect for servo lead connectors and some other RC crimp connectors.
  • Capability: 0.08-0.5mm², AWG 28-20. IWS-2820 does many mini micro sizes like U-barrel or stamped style terminals. Perfect crimps pins such as JST VH, XH, NH pins, Molex KK, Picoblade series, etc.
  • Ultra-precision: Presicion Crimping Plier with double-hinge mechanism that keeps the jaws parallel for a straight crimping engagement and ensures excellent and accurate crimps.
  • Ergonomic Design: Black oxide steel with rust resistant protect. TPR+PP grips, light and compact, provide comfortable using experience and reduce fatigue when crimps. Spring loaded handles for easy operation and storage.
  • Applications: Used to connect electrical wires on rechargeable battery packs, battery balancers, battery eliminator circuits, 3D printers, and radio controlled servos.

A faster approach to:

Open Barrel Connectors

JST SH | GH | PH | XH | ZH | Dupont | Jumper Wire

Standards of a Good Crimp

Wire crimping is a small part of a big process, however, when done correctly, it can have lanrge consequences on your day-t-day operations. This is because if a barrel and wire are not crimped properly, it creates an opening for external forces, such as moisture to enter.

open-barrel-crimper.jpg__PID:b8c4a3b7-2a30-4fc3-a7be-04e177560a53
weight.jpg__PID:1ecf83b4-04a0-4caa-bd9b-9cd5ae1cb4f2

Weight

0.6 lbs / 0.3 kg

length.jpg__PID:df1ecf83-b404-40cc-aa3d-9b9cd5ae1cb4

Length

7.09 inches / 18 cm

capacity.jpg__PID:041adf1e-cf83-4404-a0cc-aa3d9b9cd5ae

Capacity

AWG 28-20

crimp-profile.jpg__PID:1adf1ecf-83b4-44a0-8caa-3d9b9cd5ae1c

Crimp Profile

B Crimp

Trustworthy Crimp Tools

of Various Terminal

IWS-2820M Open Barrel Micro Connector Crimper Tool

  • Crimps AWG28-20 wires across 80 different pins (& D-SUB connector contacts) from the main crimp pin manufacturers (Molex, JST, Tyco, AMP, HRS, JAE etc.)
  • Professional results (& at a fraction of the cost as charged by the Pin Vendors for their specific crimping tools)
  • 6 different crimping die widths - 0.7mm, 1.0mm, 1.3mm, 1.6mm, 1.9mm, 2.2mm
  • Capable of crimping 1.25 to 2.5mm pitch connector pins (narrow-pitch)
  • Spring loaded handles for easy operation (handles latch shut for storage)

Why IWISS?

  • Founded in 2008 with production lines for cable and pipe tools
  • 85 global patents for designs and inventions
  • Various products with thousands of positive reviews
  • Best seller in electrical and piping industry
  • More than 12 overseas warehouses across the world
  • Implementing ISO 9001:2015 quality management system and 100% quality control inspection throughout production
  • Over 1.5 million end users employ iCrimp tools as their handy partner
  • Continuous market research in automotive, electrical, electronics and HVAC industries to pursue persistent innovation
  • Designed to conform to DIN, MIL, JIS, ASTM standards
