APPLICATION · CONFIGURATION · TECHNICAL DETAILS
IWS-6
- Selected model / option
- IWS-6
- SKU
- IWS-6
Working range: AWG 16–10. For the listed non-insulated terminals. Match the terminal barrel to the marked die; this is a single tool, not a connector assortment.
Application and technical information
IWS-6 Non-insulated Terminal Crimping Tool for AWG16-10 Butt/Spice/Open/Plug Connectors
IWS-6 — review the application, configuration and working range below before ordering.
- Precision ratchet system makes it stable to hold terminals. Elastomer grips fit comfortably in hand. Durable dies made of chrome-molybdenum steel.
- Colored size marks help you to check the size of crimping die even in the environment where is unsufficiently lightly and improve your work efficiency.
- Crimps non-insulated 16-10 AWG solderless terminals and connectors for for auto electrical, marine and motorcycle wiring repairs or loom assembly.
- Continuous durability test 30,000 times. Tensile test. Salt water spraying. Heat aging. Electrical resistance. Vibration fatigue.
Non-Insulated Terminal Crimp Tools
Non-insulated terminals that are used to mate, connect, or terminate single or twin wires, while allowing for a connection to a screw or stud type electrical connection. Non-insulated is best suited when special performance or installation characteristics are not needed. iCrimp non-insulated connector crimping tools are high leverage crimpers designed to work on non-insulated ring and spade terminals, butt connectors.
- The long arms require minimal force to make a strong crimp on your connectors.
- The ratcheting design ensures a proper crimp is made every time.
- The tool features a quick release if you need to abort your crimp mid-termination.
- Commonly used in automotive and marine vehicles, but can also be used in other various electrical applications.
IWS-6 — specifications
| Item Weight |
0.27 kg |
| Grip Type |
Ergonomic |
Choose the correct configuration
Compare the exact model, working range, application and included items before ordering. Replacement components and complete kits are distinct configurations.
What information helps confirm fit?
Send the model you are considering, component part number, size and a clear photo of the intended application to our support team.
How can I confirm the right model before ordering?
Email sales@iwiss.com with the model, application, component size and a photo or part number. For delivery and returns, see our shipping information and returns policy.
Match the terminal, not just the wire gauge
Check the terminal part number, barrel construction, conductor size, insulation support and required crimp geometry. Solid contacts, stamped contacts, ferrules and cable lugs use different tooling. Gauge alone does not establish compatibility.
Preparation and inspection
Identify the terminal and wire; strip to the specified length; position in the matching tooling; complete the operating cycle; inspect and test the first sample before continuing.
Check this configuration before ordering
Send the selected model, component part number, dimensions and a clear application photo to sales@iwiss.com. For a kit, check the supplied-item list; tools or consumables in application images are not automatically included.
